Miniature Ball Guide Bushing
Miniature Ball Guide Bushing is a compact precision component designed to support controlled linear movement in small-scale mechanical systems. It enables accurate guidance within tight installation spaces and ensures reliable motion consistency. Built for micro applications, it delivers stable operation, smooth performance, and dependable alignment in electronics, medical, and precision automation equipment.
- Space Saving Layout: Fits ultra small assemblies
- Precision Repeatability: Ensures consistent motion output
- Smooth Transmission: Reduces mechanical resistance
- Stable Micro Operation: Supports delicate systems consistently
Product Description
Introduction
Miniature Ball Guide Bushing is a high-precision micro linear motion component designed for compact mold systems and precision mechanical assemblies. It uses a recirculating ball structure to achieve ultra-smooth guiding and accurate positioning in extremely limited installation spaces. This makes it ideal for applications where both space efficiency and motion accuracy are critical. It ensures stable alignment and consistent performance in micro-scale industrial equipment.
Manufactured from premium hardened steel or bearing steel, Miniature Ball Guide Bushing delivers excellent wear resistance, high rigidity, and long service life despite its compact structure. Advanced micro CNC machining, precision grinding, and strict assembly control ensure extremely tight tolerances at micro-level accuracy. The internal ball circulation system significantly reduces friction, allowing smooth linear movement even under high-speed and continuous operation conditions, while maintaining stable guiding performance and minimizing energy loss.
Miniature Ball Guide Bushing is widely applied in electronics manufacturing, semiconductor equipment, medical devices, optical instruments, robotics, and precision automation systems. It supports both standard and customized designs, including micro inner diameters, outer diameters, and specialized lubrication solutions. Its flexibility and reliability make it an essential component for high-tech industries requiring ultra-precise motion control, compact structural design, and long-term operational stability in demanding micro-engineering environments.
Specifications
| Item | Description |
|---|---|
| Product Name | Miniature Ball Guide Bushing |
| Structure Type | Recirculating Ball Type |
| Material | Bearing Steel / Hardened Steel |
| Hardness | HRC 58–62 |
| Tolerance | Ultra-precision (±0.001–0.002 mm) |
| Inner Diameter | Standard / Customized Micro Size |
| Outer Diameter | Standard / Customized Micro Size |
| Length | Customizable |
| Surface Finish | Precision Ground / Polished |
| Lubrication | Grease / Micro Oil System |
| Manufacturing Process | Micro CNC Machining + Grinding + Assembly |
| Customization | OEM / ODM Available |
