Inclined Guide Pillar System
An inclined guide pillar system is a precision mold guiding mechanism designed to provide angled motion control and accurate alignment in complex injection molds and stamping dies. The inclined guide pillar system enables synchronized movement between mold components through a specially designed angular guide structure, ensuring smooth operation during opening and closing cycles.
- Product Material: SUJ2 / SKD11 /20Cr
- Product Hardness: HRC58
Product Description
Introduction
The inclined guide pillar system improves mold efficiency by enabling precise angled guidance, reducing mechanical interference, and ensuring stable synchronization between moving parts. Compared with standard straight guide systems, it offers greater design flexibility, improved motion control, and enhanced durability under complex molding conditions. This system is widely used in automotive mold manufacturing, precision stamping, electronics housing production, and advanced injection molding applications where complex structure design, high accuracy, and reliable performance are required.
Three Key Customization Aspects, Tailored to Your Needs
Matching different customization methods to meet various requirements.
Precision Manufacturing, Excellent Quality
High Hardness
Strong stamping resistance. The guide bushing is made from SUJ2 material and undergoes carburizing heat treatment, offering high hardness and a 30% improvement in wear resistance.
High Precision Fit
The guide pillar and guide bushing feature high-precision sliding fit, with a clearance coefficient of less than 0.005mm.
High Concentricity
Concentricity within 0.01mm, offering better perpendicularity and a more precise fit with the mold, effectively enhancing interchangeability.
High Precision Tolerance
The guide pillar sliding tolerance is within -0.010 to -0.015mm, offering higher perpendicularity for easy assembly.
Refined Service, Shortened Delivery Time
From design review to delivery, we provide dedicated one-on-one follow-up throughout the entire process.
Consultation → Provide Drawings → Design Review & Quotation → Order Processing → Quality Inspection → On-time Delivery → After-sales Follow-up
