Positioning Guide Bushing
Positioning Guide Bushing is designed to support precise mold assembly by ensuring accurate alignment between locating components and mold base structures. It provides stable positioning control during installation and repeated production operations, helping maintain consistent structural coordination. With reliable performance and controlled guiding characteristics, it is suitable for industrial environments that require repeatable assembly accuracy, stable operation behavior, and long-term functional consistency under continuous manufacturing conditions.
- Reliable Mold Position Locking: ensures stable assembly alignment
- Minimized Installation Alignment Error: improves setup precision
- Consistent Structural Fit Performance: maintains accurate engagement
- Enhanced Long Cycle Stability: supports durable operation reliability
Product Description
Introduction
Positioning Guide Bushing is a precision component used in mold systems to ensure accurate alignment and stable positioning between guide pillars and mold base structures. It helps maintain correct assembly orientation during installation and repeated production cycles, reducing positional deviation and improving overall mold assembly accuracy. This makes it an essential part for achieving consistent and reliable mold setup performance in industrial applications.
The product is manufactured from high-quality bearing steel, alloy steel, or hardened tool steel, and processed through heat treatment and precision machining. These manufacturing processes ensure excellent hardness, strong wear resistance, and stable dimensional accuracy under continuous operation. The inner surface is finely ground to ensure smooth engagement with guide pins, providing reliable and repeatable positioning performance even in demanding production environments.
Positioning Guide Bushing is widely used in injection mold bases, stamping die alignment systems, plastic mold fixtures, die casting molds, automotive tooling, electronic component molds, and precision industrial equipment. It is particularly suitable for applications requiring strict positioning control and high repeatability. Compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, it can also be customized according to drawings or technical requirements, making it a dependable solution for improving alignment accuracy, reducing assembly errors, and ensuring long-term stability in modern manufacturing systems.
Specifications
| Item | Description |
|---|---|
| Product Name | Positioning Guide Bushing |
| Material | SUJ2, GCr15, SKD11, Alloy Steel |
| Hardness | HRC 58–62 |
| Structure Type | Straight / Flanged / Custom Type |
| Surface Finish | Precision Ground |
| Function Type | Positioning / Alignment Support |
| Tolerance | High Precision Standard |
| Size Range | Standard and Custom Sizes |
| Service Life | Long Cycle Industrial Use |
